Geology and Geography
Schouten Island is 1.6 km south of Freycinet Peninsula, located at 42° 18’ 46.8” S, 148° 16’ 30” E, and separated by a sheltered stretch of water known as Schouten Passage. It is Tasmania's 11th largest island being approximately 9.5 km wide, 5.7 km long and 3,439ha in area. The highest point is Mt Storey, at 420 metres. Mt Deadalus is the summit peak of a large granite area and small tin workings can also be observed in this region.
Although approximately 80% of the Freycinet Peninsula is composed of granite, Schouten Island is bisected by a fault line running from the north to the south.
The north-south fault line that divides the island means that the eastern part of the island is composed of granite while the western part is dolerite capped lithic sandstone.
This difference in geology also becomes apparent when observing the vegitation of the island, with different soil types affecting the species of flora. (see )
​
Unnamed headland on north-east coast of Schouten Island-
http://dpipwe.tas.gov.au/Documents/Schouten-Island-Report.pdf
Geography of Schouten Island:
Schouten Island is 1.6 km south of Freycinet Peninsula, located at 42° 18’ 46.8” S, 148° 16’ 30” E, and separated by a sheltered stretch of water known as Schouten Passage. It is Tasmania's 11th largest island being approximately 9.5 km wide, 5.7 km long and 3,439ha in area.
While the geology of Schouten Island differs from that of the Freycinet Peninsula, the topography is relatively similar in both. Elevated coastline of rugged cliffs can be found to the East and South, and a coastline of sandy beaches alternating with cobble beaches to the North. At either end of the fault line that divides the two portions of the island are sandy bays forming anchorages for vessels (depending on wind direction).
Key topographical features and major landforms include Mt Storey in the south, which is the highest point on the island (420m), near Mt Storey lies Mt Deadalus (400m) and Bear Hill in the north (299m).
The topography of the island can be divided into two sections, based on the rock types comprising these landforms. The granite eastern section is primarily composed of steep, rounded bare peaks and ridges, varying in height (1000-1500ft).
The western part of the island consists of only one major landform, being a gently sloping dolerite hill (900ft). Forming the Western shoreline and surrounding the periphery of the hill are sandstones and shales that rise in sharp cliffs (maximum height of 250ft).
​
Slightly flared granite slope, northern ridge of Bear Hill-
http://dpipwe.tas.gov.au/Documents/Schouten-Island-Report.pdf
Geology of Schouten Island:
Due to the north-south fault line that bisects Schouten Island through its centre, the geology of the island is remarkable. The Eastern part of the island is composed of granite, while the western portion of the island is dolerite overlying sedimentary and supergroup rocks.
Granite is the most common igneous rock that is found on the earth's surface. It is formed from the slow crystallization of magma below the earth's surface. Granite is usually composed of feldspar and quartz with small amounts of mica, amphiboles and other minerals. The mineral composition of granite usually gives it a red, white, pink or gray coloration with darker grains visible.
Example of Granite sourced from Eastern Crocketts Bay
http://dpipwe.tas.gov.au/Documents/Schouten-Island-Report.pdf
Tasmania is home to the earth's biggest exposure of Dolerite (also known ia Diabase). Dolerite is a medium grained rock which contains pyroxene, plagioclase and olivine. It is usually dark in colour and typically occurs in sills (also known as a sheet, a flat intrusion of igneous rock that forms between already existing layers of rocks) and dykes (a sheetlike steeply vertical igneous body that incline to the bedding of preexisting intrusive rocks).
​
Example of a regular peice of Dolerite
http://www.sandatlas.org/diabase/
Small quartz reefs are common on the island, and one particular reef situated on the southern area of the island, is up to 25ft wide and extends several hundred metres.
Joints (fractures in rocks that divide it into two sections, without moving them away from one another) are common on Schouten Island and have been observed to run most frequently in two main directions, 100 degrees (roughly east), and 340 degrees (roughly north-west).
The process of weathering rapidly wears away the rocks along these joints, creating blocks of granite that have been naturally worn and carved into different sculptured shapes.
​
​
Example of striped Leisegong Banding on a cliff.
​http://dpipwe.tas.gov.au/Documents/Schouten-Island-Report.pdf
How the Geography of Schouten Island was Formed:
Schouten Island took over 375 million years to form into the island it is now.
To fully understand the geology of Schouten Island, we must attempt to understand exactly how the island was formed and what geomorphic processes created its fascinating geology.
During the Paleozoic Era (period of change from about 542 million years ago, to about 251 million years ago), the bedrock of Eastern Tasmania was deposited on the strata called the Mathinna Supergroup.
400 million years ago (mya), off the edge of a continental shelf, layers of mud and sand accumulated. This sometimes occured due to underwater landslides, and also happened slowly in still water. During this time, Eastern Tasmania was very close to the equator.
380 mya: Collision of two tectonic plates compressed the layers of rocks, folding and faulting them. The high mountain range that was created began to drift slowly downwards.
370 mya: Folding and faulting caused weaker areas in the Earth's crust, through which huge masses of molten granite pushed upwards and melted the sedimentary rocks. When the magma cooled, solid granite remained, surrounded by baked sediments. Much of the sediments previously covering the granite was eroded to expose the bare granite at the surface.
290 mya: As Tasmania was moved closer to the Polar Region by continental drift, the East Coast sunk into the sea and glaciers dropped large stones into small sediments which then buried the granite under several layers.
170 mya: Instead of being compressed, upwelling magma forced apart the crust along the East Coast of Tasmania. Large masses of dolerite were pushed between horizontal layers previously deposited. As the crust slowly rifted, the Tasman Sea began to open up.
The faulting occured on Schouten Island during this this time, and caused the prominent division in the island's geology.
60 mya: As the Tasman Sea opened up further, some blocks of land were lifted up while others sunk. What is now the Freycinet Peninsula became a low range, while Great Oyster Bay opened up as earthquakes caused underlying rocks to sink downwards.
2 mya: The earth entered the Ice Age. During a series of glacial periods, Tasmania was covered with ice. However, there was not enough precipitation on the East Coast to build up large snow banks.
Today and Onwards: Weathering and erosion of the granite areas continues today, and this can be observed in the discolouration on rock surfaces where water emerges from joints.
Devonian: The devonian granite that makes up the the Eastern half of the island is the same as the red granite produced at Coles Bay used for architecture. Red granite usually consists of course graicontaining a large amount of orthoclase, which gives it the reddish appearance. Separate patches of finer grained granite are also present on Schouten Island, however they are infrequent and contain the same minerals and are the same age as the more common coarser type.
Permian: Rocks that date back to the Permian age have been reported on Schouten Island, consisting of two small rocks that lie at either ends of the fault line, which separates the granite and dolerite areas.
On the northern coast, there is a small outcrop of indurated siltstone, approximately 15ft long and 14ft wide.
On the southern coast, the area where the fault line meets the sea is a small bay edged with Permian Cliffs, 35ft in height, over which flows a small creek.
These Permian cliffs, while they are limited in area, are very prominent. They are similar to the famous Tessellated Pavement, at Eagle Hawk Neck, located on the Tasman Peninsula.
Triassic: The two main divisions of the Triassic are very prominent on Schouten Island; the Knocklofty or Ross sandstones and shales which are large, prominent cliff sections and the Feldspathic Sandstone, which contains coal.
The main exposures of the triassic Ross Sandstone and shales are along the western coastline. They form steep cliffs that rise up to 250ft above the water.
The Feldspathic sandstones are not as prominent as the Ross Sandstone and only occupies narrow coastal areas over short distances.
Jurassic: The typical Jurassic dolerite occupies the majority of the Western half of the island, and rises to a height of about 900ft above sea level.
​
​
​
Tor on Bear Hill that resembles a smiling elderly man formed by geomorphic processes.
http://dpipwe.tas.gov.au/Documents/Schouten-Island-Report.pdf
​
Example of erosion caused by salt spray on this sea cliff, Wsetern side of Schouten Island.
http://dpipwe.tas.gov.au/Documents/Schouten-Island-Report.pdf
​
Schouten Island Fault Line:
The large fault line which is a prominent geological feature of Schouten Island, separates the Devonian granite and the Silunian sediments from the Permian-Triassic rocks with their dolerite intrusions is very well represented on the island. The fault zone itself is very wide and straight, striking almost due north with a westward swing near the top of the island. In the fault zone are blocks of Permian rocks and Triassic sandstone (Ross Sandstone). These have been caught up in the earth movement and remnants of which have survived erosion and can be observed at either ends of the fault line.
​
